General characteristics:

"U" type clamp is required, depending on the diameter of the pipe (1/2" to 2").

Automatic tube outlet plate MG51109

Measurement: 2.6" (66mm)

Galvanized Electro-Zinc.

General characteristics:

To join sections with an elevation of 2.12" (54mm)

Available in polyester paint.

Electro Zinc finish.

Fixing tool: MG51906 Sold separately

Batteries with Technology AGM / VRLA

SYSCOM has released its recommendations for batteries in electronic equipment, especially those back-ups, ceasing to be considered an unimportant accessory to become frontline actors in availability to 100% in systems electronic security.

You should demand the best quality in their batteries since, in normal operation, they will be exposed on one side to the action of the local physical environment (temperature and humidity, mainly); on the other, you may be embedded in a non-friendly environment. These are some of the reasons that the batteries must be reliable in terms of their operation, and maintenance requirements should be minimal and simple.

SYSCOM strongly recommends using AGM / VRLA brand EPCOM POWER LINE batteries with a variety of them, from 1.2 Ah to 110 Ah at 12 Vdc.

 Applications

• Access control systems.
• Intrusion alarm systems.
• CCTV systems.

Characteristics

• High-performance batteries.
• Designed for high-reliability applications.
• Manufactured under the highest quality standards.
• Tested for 24/7 performance.
• 12 Ah capacity.
• Voltage (Vdc): 12.
• Terminal type : F2
• Type: AGM / VRLA.
• Width: 3.85" (98 mm).
• Height: 3.74" (95 mm).
• Depth: 5.94" (151 mm).
• Weight: 8.15 lb (3.7 kg).

* 1-year warranty.


Main features:

What additional components should you quote to arm a complete system?

Step 1 Select a mast and installation kit

Octagonal arm without accessories 1601-555, requires an installation kit 1601-242.

Octagonal arm with reverse edge sensor 1601-555, requires an installation kit 1601-235 and a reverse edge sensor 8080-080.

Octagonal lighted arm with reverse edge sensor RED / GREEN 1601-555, requires installation kit 1601-235 and a lighted reverse edge sensor 8080-096

Octagonal arm with reverse edge sensor and breakaway system 1601-555, requires installation kit with breakaway system 1601-295 and a reverse edge sensor 8080-080

Octagonal lighted arm with reverse edge sensor RED / GREEN  and breakaway system 1601-555, requires installation kit with breakaway system 1601-295 and a lighted reverse edge sensor 8080-096

Step 2 Choose optional accessories.

Mass sensor DKS original 9410-010, requires magnetic loop SYSLM6

3-push button control for vehicle access applications XBSSW01

Photoelectric detector with 22 ft (7 m) range XBSRR7

Security laser for vehicle access applications 10LZR-H100-KIT19327

Traffic light for Doorking barriers 1603-222

Additional Notes and Recommendations

• All components and accessories are sold separately.
• Vehicle access devices require installation by certified personnel.
• The 5-year warranty applies to models 1601-080.
• The warranty specifically covers damage and/or malfunction resulting from a manufacturing defect in the product.
• Any damage caused by improper operation or installation invalidates the product warranty policy.
• Compliance with the UL325 standard requires the use of additional safety devices. For more information, you can consult the following link UL 325, Safety Standard.
• In order to ensure better protection against electric shock, it is necessary to connect an Earth line to the designated terminals on the vehicle barrier and add a line protection device against electric shock.

Main features:

NOTE: Consider using XB-POST armrests for arms of 4 meters or more to prevent premature mechanism damage.

ADDITIONAL NOTES

The barrier is prepared to work with an arm with a distance of 5 to 6 meters. Having an arm with a different distance requires changing springs.

To know what type of spring should be used, we can refer to the following TABLE

Barrier only compatible with XB-TEL-ARMB1 arm.

In a correct adjustment of the opening and closing limits, our mechanism should not reach the physical limits.

If your mechanism is reaching the physical limits, please review the following VIDEO.

NOT compatible with illuminated arms.

Base Mounting for LED Obstruction Lamp

This mounting base is designed for LED obstruction lamp models EI-LBIB and EI-GSL-SE / GSLID. Constructed from 16 gauge steel sheet with electrostatic paint finish in beige, it provides structural support for strobe mounting applications on towers. The base includes U-bolts with nuts for tube diameters from 7/8 inch to 1-1/4 inch, and features provisions for additional clamp or strap installation on larger diameters. Hardware is included for immediate field installation.

Main Features

• 16 gauge galvanized steel sheet construction
• Compatible with EI-LBIB, EI-GSL-SE and GSLID lamps
• U-bolts with nuts for 7/8" to 1-1/4" tube diameters
• Pre-drilled for additional clamp or strap (not included)
• Beige electrostatic paint finish
• Shipped in cardboard box with mounting hardware

Typical applications: Tower strobe mounting for aviation obstruction lighting, telecommunications infrastructure, and broadcast tower installations.

Compatible with: PR233, PR234, AYK12, AYH12, AYK25, AYF64, SYSKR600E, SYSKR601E, SYSKR600M, SYSKR602EKB; and standalone readers ACF43, ACF44, ACQ44, 9325I, 9325E.

• Allows free passage of 0-gauge wire.

• Color: black.

• Sheet gauge: 14 and 18.

• Cover mounting with screws.

• The cable outlet at the bottom (floor).

• Dimensions: 4.56 X 43 X 8.74" (116 x 1092 x 222 mm)

• Weight: 8.37 lb (3.8 kg)

High-quality output button for access control applications.

Features
- Access control

Capacity
- Cards: 30,000
- Passwords: 30,000
- Events: 100,000
(Event memory expandable with SD Memory up to 32GB)

Communication
- TCP / IP and RS485
- Input: multi-format Wiegand

Hardware
- Metal cabinet
- Includes 12VDC / 3A power (Battery not included).

Access Control Functions
- Access control by schedules and doors
- Combinables verification methods:
   • Card + Password (with reader model SYSKR602EKB)
- Multi-user verification
- Interlock
- Anti-passback
- Energized relay function

Connections
- 4 relay output NC / NO / COM for board
- 4 Auxiliary relay output NC / NO / COM
- 4 Auxiliary output
- Exit button and magnetic sensor

Power
- 12VDC / 100mA
- Includes 12VDC / 3A power

Compatible Readers
- Proximity:
   • SYSKR600E and SYSKR601E
   • Supports 2 readers per door

- Proximity with the keyboard:
   • SYSKR602EKB
   • Supports 2 readers per door

- Long Range Readers:
   • PRO6RF and PRO12RF
   • Supports 2 readers per door


Additional Information
- Operating Temperature: 0-55 ° C
- Dimensions: 380 x 290 x 80 mm
- Includes Management Software (in Spanish)

*1 Year Warranty


Configurations







* Price per unit.

4-conductor cable 22 Gauge with white lining for applications in alarm, access control, intercoms, and tv porteros.

Soft solid copper conductors PVC insulation, identified by color coding, and an overall PVC jacket.

Using applications alarms, sensor wiring, wiring sirens, intercoms and TV wiring doormen, bellhops and magnetic contacts on access control.

* Price for Reel 1000 ft


*Price per unit

Jack female connector cable 0.13" (3.5 mm)  jack plug with 4 outputs

Features:

• High quality
• A convenient and cost-effective way to power up 4 cameras with 1 power adapter
• Plug Diameter: Outer: 0.22" (5.5mm), Inner: 0.08" (2.1mm)
• DC Female Power Splitter Cable
• Length : 13.78" (35 cm)
• Included: 1 x DC Power 1 Female to 4 Male Splitter Cable

Card Holder Imitation Leather

Practical for printed cards that cant be perforated

Fits thin cards (PVC or ISO).

Brown color

Note.- does not include a lanyard.

Card Holder for Vehicle Windshield

The ACCESS-HOLDERA is a card holder designed for vehicle access control applications. Manufactured in transparent ABS plastic, it enables visual identification of the enclosed card while providing secure retention. The unit includes suction cups for attachment to vehicle windshields, facilitating hands-free proximity reading at entry points. Its compact form factor accommodates standard card formats commonly used in parking and fleet management systems.

Main Features

• Compatible with ACCESSCARDEPC and PROCARDX card formats
• Transparent ABS plastic construction for visual card identification
• Includes suction cups for windshield mounting
• Compact dimensions: 90 x 57 x 5 mm
• Secure card retention for vehicular environments

*Card not included. Image shown is for illustrative purposes only.

.
